SKU: UCFC215D1-NTN
NTN UCFC215D1 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert - Allow 2-3 Days
NTN UCFC215D1 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert - Allow 2-3 Days
Regular price
$197.87
ex VAT
Regular price
Sale price
$197.87
ex VAT
In stock
Price Break
3+
$132.54
4+
$125.09
9+
$123.60
19+
$122.11
49+
$120.63
99+
$119.14
499+
$111.69
999+
$110.20
1999+
$108.71
2999+
$107.22
4999+
$104.24
Quantity
Couldn't load pickup availability
Description
Description
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 75mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 130.1mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 75mm |
| L | 220mm |
| J | 184mm |
| (J<sub>1</sub>) | 130.1mm |
| A<sub>2</sub> | 18mm |
| N | 19mm |
| A<sub>3</sub> | 16mm |
| A<sub>1</sub> | 40mm |
| A | 56mm |
| H<sub>3</sub> | 160mm |
| A<sub>0</sub> | 78.5mm |
| B | 77.8mm |
| S | 33.3mm |
| F (Min.) | 100mm |
| Fixing bolt | M16 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 73.5 kN |
| Static load C<sub>0r</sub> | 49.5 kN |
| Fatigue load limit C<sub>u</sub> | 3.8 kN |
| --- | Unit information |
| Mass | 7.4 kg |
