SKU: UCFCX06D1-NTN
NTN UCFCX06D1 Metric Four Bolt Cast Iron Round Flanged Housing with 30mm Insert - Allow 2-3 Days
NTN UCFCX06D1 Metric Four Bolt Cast Iron Round Flanged Housing with 30mm Insert - Allow 2-3 Days
Regular price
$52.92
ex VAT
Regular price
Sale price
$52.92
ex VAT
In stock
Price Break
3+
$35.45
4+
$33.46
9+
$33.06
19+
$32.66
49+
$32.26
99+
$31.86
499+
$29.87
999+
$29.47
1999+
$29.08
2999+
$28.68
4999+
$27.88
Quantity
Couldn't load pickup availability
Description
Description
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 30mm
- Style:
- UCFCX
- Pitch Circle Diameter:
- 74.2mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 30mm |
| L | 127mm |
| J | 105mm |
| (J<sub>1</sub>) | 74.2mm |
| A<sub>2</sub> | 8mm |
| N | 12mm |
| A<sub>3</sub> | 9.5mm |
| A<sub>1</sub> | 22.5mm |
| A | 32mm |
| H<sub>3</sub> | 85mm |
| A<sub>0</sub> | 42.9mm |
| B | 42.9mm |
| S | 17.5mm |
| F (Min.) | 52mm |
| Fixing bolt | M10 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 28.4 kN |
| Static load C<sub>0r</sub> | 15.3 kN |
| Fatigue load limit C<sub>u</sub> | 1.09 kN |
| --- | Unit information |
| Mass | 15 kg |
