• NTN UCFX13D1 Metric Four Bolt Square Cast Iron Flange Housing with 65mm Bore Insert - Allow 2-3 Days
  • NTN
1 2

SKU: UCFX13D1-NTN

NTN UCFX13D1 Metric Four Bolt Square Cast Iron Flange Housing with 65mm Bore Insert - Allow 2-3 Days

NTN UCFX13D1 Metric Four Bolt Square Cast Iron Flange Housing with 65mm Bore Insert - Allow 2-3 Days
$140.71 ex VAT
$140.71 ex VAT
Sale Sold out

In stock

Price Break
3+ $94.25
4+ $88.96
9+ $87.90
19+ $86.84
49+ $85.78
99+ $84.72
499+ $79.43
999+ $78.37
1999+ $77.31
2999+ $76.25
4999+ $74.13

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
NTN - High Quality
Inside Diameter:
65mm
Style:
UCFX
Bolt Hole Centres:
149mm
Technical
--- Dimensions
Shaft diameter 65mm
L 187mm
J 149mm
A<sub>2</sub> 34mm
A<sub>1</sub> 21mm
A 59mm
N 19mm
A<sub>0</sub> 78.4mm
B 74.6mm
S 30.2mm
Fixing bolt M16
--- Load rating
Dynamic load C<sub>r</sub> 69 kN
Static load C<sub>0r</sub> 44 kN
Fatigue load limit C<sub>u</sub> 3.45 kN
--- Unit information
Mass 6.6 kg
