• NTN UCFX15-215D1 Imperial Four Bolt Square Cast Iron Flange Housing with 2-15/16 inch Bore Insert - Allow 2-3 Days
  • NTN
1 2

SKU: UCFX15-215D1-NTN

NTN UCFX15-215D1 Imperial Four Bolt Square Cast Iron Flange Housing with 2-15/16 inch Bore Insert - Allow 2-3 Days

NTN UCFX15-215D1 Imperial Four Bolt Square Cast Iron Flange Housing with 2-15/16 inch Bore Insert - Allow 2-3 Days
$180.28 ex VAT
$180.28 ex VAT
Sale Sold out

In stock

Price Break
3+ $120.76
4+ $113.97
9+ $112.61
19+ $111.26
49+ $109.90
99+ $108.54
499+ $101.76
999+ $100.40
1999+ $99.05
2999+ $97.69
4999+ $94.98

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
NTN - High Quality
Inside Diameter:
74.61mm = 2.937 (2-15/16) inch
Style:
UCFX
Bolt Hole Centres:
5-63/64 inch
Technical
--- Dimensions
Shaft diameter 2-15/16 inch
L 7-3/4 inch
J 5-63/64 inch
A<sub>2</sub> 1-37/64 inch
A<sub>1</sub> 15/16 inch
A 2-11/16 inch
N 29/32 inch
A<sub>0</sub> 3-33/64 inch
B 3.252 inch
S 1.311 inch
Fixing bolt 3/4 inch
--- Load rating
Dynamic load C<sub>r</sub> 80.5 kN
Static load C<sub>0r</sub> 53 kN
Fatigue load limit C<sub>u</sub> 3.95 kN
--- Unit information
Mass 19 lbs
