• Challenge / FK UCPX09-28 Imperial Cast Iron Two Bolt Pillow Block Housing with 1-3/4 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
1 1

SKU: UCPX.09-28.TS.CHAL

Challenge / FK UCPX09-28 Imperial Cast Iron Two Bolt Pillow Block Housing with 1-3/4 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge / FK UCPX09-28 Imperial Cast Iron Two Bolt Pillow Block Housing with 1-3/4 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
$113.10 ex VAT
$113.10 ex VAT
Sale Sold out

Equivalent to: UCPX.09-28

In stock

Price Break
3+ $75.76
5+ $71.50
9+ $70.65
19+ $69.80
49+ $68.95
74+ $68.10
99+ $63.84
199+ $62.99
249+ $62.14
499+ $61.29
999+ $59.59

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Challenge / FK - Good Quality
Inside Diameter:
44.45mm = 1.75 (1-3/4) inch
Style:
UCPX
Bolt Hole Centres:
156mm
Technical
Shaft Diameter d 1-3/4 inch
Casting Centre Line Height h 58.7mm
Casting Length a 222mm
Recommended Bolt Centres l 156mm
Casting Width b 67mm
Slot Length s<sub>2</sub> 33mm
Slot Width s<sub>1</sub> 20mm
Foot Height g 26mm
Overall Height w 116mm
Bearing Insert Width Bi 51.6mm
Back of Bearing to Centre Line n 19mm
Bolt Size 5/8 inch
Grub Screws x 2 5/16 - 24UNF inch
Load Rating (Dynamic) 2750kg
Load Rating (Static) 2020kg
Max Speed 1900 rev/min
Working Temperature -30&deg;C to +120&deg;C
Insert No UCX09-28
Housing No PX09
