• UCPX10 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 50mm Bore Insert
1 1

SKU: UCPX.10

UCPX10 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 50mm Bore Insert

UCPX10 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 50mm Bore Insert
$97.37 ex VAT
$97.37 ex VAT
Sale Sold out

Equivalent to: MP50

In stock

Price Break
3+ $65.22
4+ $61.55
9+ $60.82
19+ $60.09
49+ $59.35
99+ $58.62
499+ $54.96
999+ $54.22
1999+ $53.49
2999+ $52.76
4999+ $51.29

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
50mm
Style:
UCPX
Bolt Hole Centres:
171mm
Technical
d 50mm
h 63.5mm
a 241mm
e 171mm
b 73mm
s2 36mm
s1 20mm
g 27mm
w 126mm
B1 55.6mm
n 22.2mm
Bolt Size M16
Weight 4.4 kg
Dynamic load 3400 kgf
Static load 2550 kgf
Rec max speed 3100 rpm
