• UCPX10-31 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-15/16 inch Bore Insert
1 1

SKU: UCPX.10-31

UCPX10-31 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-15/16 inch Bore Insert

UCPX10-31 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-15/16 inch Bore Insert
$61.42 ex VAT
$61.42 ex VAT
Sale Sold out

In stock

Price Break
3+ $41.13
4+ $38.82
9+ $38.36
19+ $37.90
49+ $37.44
99+ $36.97
499+ $34.66
999+ $34.20
1999+ $33.74
2999+ $33.28
4999+ $32.35

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
49.21mm = 1.937 (1-15/16) inch
Style:
UCPX
Bolt Hole Centres:
171mm
Technical
d 1-15/16 inch
h 63.5mm
a 241mm
e 171mm
b 73mm
s2 36mm
s1 20mm
g 27mm
w 126mm
B1 55.6mm
n 22.2mm
Bolt Size M16
Weight 4.4 kg
Dynamic load 3400 kgf
Static load 2550 kgf
