SKU: UCPX.12-39
UCPX12-39 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2-7/16 inch Bore Insert
UCPX12-39 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2-7/16 inch Bore Insert
Out of stock
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 61.91mm = 2.437 (2-7/16) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 203mm
Technical
Technical
| d | 2-7/16 inch |
|---|---|
| h | 76.2mm |
| a | 286mm |
| e | 203mm |
| b | 83mm |
| s2 | 41mm |
| s1 | 25mm |
| g | 32mm |
| w | 152mm |
| B1 | 65.1mm |
| n | 25.4mm |
| Bolt Size | M20 |
| Weight | 7.4 kg |
| Dynamic load | 4480 kgf |
| Static load | 3470 kgf |
