• Challenge / FK UCPX13-40 Imperial Cast Iron Two Bolt Pillow Block Housing with 2-1/2 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
1 1

SKU: UCPX.13-40.TS.CHAL

Challenge / FK UCPX13-40 Imperial Cast Iron Two Bolt Pillow Block Housing with 2-1/2 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge / FK UCPX13-40 Imperial Cast Iron Two Bolt Pillow Block Housing with 2-1/2 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
$271.51 ex VAT
$271.51 ex VAT
Sale Sold out

Equivalent to: UCPX.13-40

In stock

Price Break
3+ $181.86
5+ $171.65
9+ $169.60
19+ $167.56
49+ $165.52
74+ $163.47
99+ $153.26
199+ $151.21
249+ $149.17
499+ $147.13
999+ $143.04

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Challenge / FK - Good Quality
Inside Diameter:
63.5mm = 2.5 (2-1/2) inch
Style:
UCPX
Bolt Hole Centres:
203mm
Technical
Shaft Diameter d 2-1/2 inch
Casting Centre Line Height h 76.2mm
Casting Length a 286mm
Recommended Bolt Centres l 203mm
Casting Width b 83mm
Slot Length s<sub>2</sub> 41mm
Slot Width s<sub>1</sub> 25mm
Foot Height g 32mm
Overall Height w 154mm
Bearing Insert Width Bi 74.6mm
Back of Bearing to Centre Line n 30.2mm
Bolt Size 3/4 inch
Grub Screws x 2 3/8 - 24UNF inch
Load Rating (Dynamic) 4870kg
Load Rating (Static) 3810kg
Max Speed 1400 rev/min
Working Temperature -30&deg;C to +120&deg;C
Insert No UCX13-40
Housing No PX13
