• Challenge / FK UCPX15-48 Imperial Cast Iron Two Bolt Pillow Block Housing with 3 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
1 1

SKU: UCPX.15-48.TS.CHAL

Challenge / FK UCPX15-48 Imperial Cast Iron Two Bolt Pillow Block Housing with 3 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge / FK UCPX15-48 Imperial Cast Iron Two Bolt Pillow Block Housing with 3 inch Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
$486.01 ex VAT
$486.01 ex VAT
Sale Sold out

Equivalent to: UCPX.15-48

In stock

Price Break
3+ $325.55
5+ $307.26
9+ $303.60
19+ $299.94
49+ $296.28
74+ $292.63
99+ $274.34
199+ $270.68
249+ $267.02
499+ $263.36
999+ $256.05

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Challenge / FK - Good Quality
Inside Diameter:
76.2mm = 3 inch
Style:
UCPX
Bolt Hole Centres:
229mm
Technical
Shaft Diameter d 3 inch
Casting Centre Line Height h 88.9mm
Casting Length a 330mm
Recommended Bolt Centres l 229mm
Casting Width b 89mm
Slot Length s<sub>2</sub> 50mm
Slot Width s<sub>1</sub> 27mm
Foot Height g 35mm
Overall Height w 175mm
Bearing Insert Width Bi 82.6mm
Back of Bearing to Centre Line n 33.3mm
Bolt Size 7/8 inch
Grub Screws x 2 7/16 - 24UNF inch
Load Rating (Dynamic) 5700kg
Load Rating (Static) 4550kg
Max Speed 1200 rev/min
Working Temperature -30&deg;C to +120&deg;C
Insert No UCX15-48
Housing No PX15
