SKU: UCPX.16-50
UCPX16-50 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 3-1/8 inch Bore Insert
UCPX16-50 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 3-1/8 inch Bore Insert
Out of stock
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 79.38mm = 3.125 (3-1/8) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 283mm
Technical
Technical
| d | 3-1/8 inch |
|---|---|
| h | 101.6mm |
| a | 381mm |
| e | 283mm |
| b | 102mm |
| s2 | 59mm |
| s1 | 27mm |
| g | 42mm |
| w | 195mm |
| B1 | 85.7mm |
| n | 34.1mm |
| Bolt Size | M22 |
| Weight | 16.2 kg |
| Dynamic load | 6600 kgf |
| Static load | 5320 kgf |
