• Challenge UCX07-22 Imperial Insert with Grub Screws with 1-3/8 inch Bore 80mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge UCX07-22 Imperial Insert with Grub Screws with 1-3/8 inch Bore 80mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge
1 3

SKU: UCX.07-22.TS.CHAL

Challenge UCX07-22 Imperial Insert with Grub Screws with 1-3/8 inch Bore 80mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge UCX07-22 Imperial Insert with Grub Screws with 1-3/8 inch Bore 80mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
$47.10 ex VAT
$47.10 ex VAT
Sale Sold out

Equivalent to: UCX.07-22

In stock

Price Break
3+ $31.55
5+ $29.78
9+ $29.42
19+ $29.07
49+ $28.72
74+ $28.36
99+ $26.59
199+ $26.23
249+ $25.88
499+ $25.52
999+ $24.82

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

UCX Insert with Grub Screws: These normal-duty bearing units are fitted with a triple lip seal. These bearings are perfect for agricultural applications where the bearings are exposed to contamination. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. Also available as a complete housing assembly.
Benefits: High tolerance to harsh environments, cost effective bearing, re-lubricatable, grub screw fixing

Brand / Quality:
Challenge - Good Quality
Inside Diameter:
34.93mm = 1.375 (1-3/8) inch
Style:
UCX
Technical
Shaft Diameter d 1-3/8 inch
Outside Diameter D 80mm
Overall Width Bi 49.2mm
Inner Race Width Be 22mm
Back of Bearing to Centre Line n 19mm
Front of Bearing to Centre Line m 30.2mm
Dimension G 8mm
Grub Screws x 2 5/16 - 24UNF inch
Load Rating (Dynamic) 2560kg
Load Rating (Static) 1810kg
Max Speed 2400 rev/min
Working Temperature -30°C to +120°C
Reviews
View full details
