• Challenge UCX11-36 Imperial Insert with Grub Screws with 2-1/4 inch Bore 110mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge UCX11-36 Imperial Insert with Grub Screws with 2-1/4 inch Bore 110mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
  • Challenge
1 3

SKU: UCX.11-36.TS.CHAL

Challenge UCX11-36 Imperial Insert with Grub Screws with 2-1/4 inch Bore 110mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge UCX11-36 Imperial Insert with Grub Screws with 2-1/4 inch Bore 110mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
$97.14 ex VAT
$97.14 ex VAT
Sale Sold out

Equivalent to: UCX.11-36

In stock

Price Break
3+ $65.07
5+ $61.41
9+ $60.68
19+ $59.95
49+ $59.22
74+ $58.49
99+ $54.83
199+ $54.10
249+ $53.37
499+ $52.64
999+ $51.18

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Challenge - Good Quality
Inside Diameter:
57.15mm = 2.25 (2-1/4) inch
Style:
UCX
Technical
Shaft Diameter d 2-1/4 inch
Outside Diameter D 110mm
Overall Width Bi 65.1mm
Inner Race Width Be 27mm
Back of Bearing to Centre Line n 25.4mm
Front of Bearing to Centre Line m 39.7mm
Dimension G 10mm
Grub Screws x 2 3/8 - 24UNF inch
Load Rating (Dynamic) 4100kg
Load Rating (Static) 3150kg
Max Speed 1600 rev/min
Working Temperature -30°C to +120°C
