SKU: UELFC212D1-NTN
NTN UELFC212D1 Metric Four Bolt Cast Iron Round Flanged Housing with 60mm Eccentric Collar Insert - Allow 2-3 Days
NTN UELFC212D1 Metric Four Bolt Cast Iron Round Flanged Housing with 60mm Eccentric Collar Insert - Allow 2-3 Days
Regular price
$147.31
ex VAT
Regular price
Sale price
$147.31
ex VAT
In stock
Price Break
3+
$109.74
4+
$105.31
9+
$103.09
19+
$99.77
49+
$97.55
99+
$92.01
499+
$77.60
999+
$0.00
1999+
$0.00
2999+
$0.00
4999+
$0.00
Quantity
Couldn't load pickup availability
Share this product
Description
Description
UELFC200 Series 4 Bolt Cast Iron Round Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the round cast iron housing and include a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar with a grub screw to facilitate securing the bearing to the shaft after installation. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar/grub screw fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 60mm
- Style:
- UELFC
- Pitch Circle Diameter:
- 113.1mm
Technical
Technical
| Shaft diameter | 60mm |
|---|---|
| L | 195mm |
| J | 160mm |
| (J<sub>1</sub> | 113.1mm |
| A<sub>2</sub> | 17mm |
| N | 19mm |
| A<sub>3</sub> | 12mm |
| A<sub>1</sub> | 36mm |
| A | 48mm |
| H<sub>3</sub> | 135mm |
| A<sub>0</sub> | 75.85mm |
| B<sub>1</sub> | 77.8mm |
| S | 30.95mm |
| F min. | 84mm |
| Fixing bolt | M16 |
| Mass | 5.2 kg |
