SKU: UELFL208-108D1-NTN

NTN UELFL208-108D1 Imperial Two Bolt Cast Iron Oval Housing with 1-1/2 inch Bore Eccentric Collar Insert - Allow 2-3 Days

NTN UELFL208-108D1 Imperial Two Bolt Cast Iron Oval Housing with 1-1/2 inch Bore Eccentric Collar Insert - Allow 2-3 Days

Out of stock


Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Shaft diameter 1-1/2 inch
H 6-7/8 inch
J 5-43/64 inch
A<sub>2</sub> 53/64 inch
A<sub>1</sub> 19/32 inch
A 1-13/32 inch
N 5/8 inch
L 3-15/16 inch
A<sub>0</sub> 2-13/64 inch
B<sub>1</sub> 2.217 inch
S 0.843 inch
F min. 2-1/4 inch
Fixing bolt 1/2 inch
Mass 3.5 lbs
