SKU: UELFL212D1W3-NTN
NTN UELFL212D1W3 Metric Two Bolt Cast Iron Oval Housing with 60mm Bore Eccentric Collar Insert - Allow 2-3 Days
NTN UELFL212D1W3 Metric Two Bolt Cast Iron Oval Housing with 60mm Bore Eccentric Collar Insert - Allow 2-3 Days
Regular price
$147.24
ex VAT
Regular price
Sale price
$147.24
ex VAT
In stock
Price Break
3+
$109.69
4+
$105.26
9+
$103.04
19+
$99.72
49+
$97.50
99+
$91.96
499+
$77.56
999+
$0.00
1999+
$0.00
2999+
$0.00
4999+
$0.00
Quantity
Couldn't load pickup availability
Share this product
Description
Description
UELFL200 Series 2 Bolt Cast Iron Oval Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar to allow tightening against the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 60mm
- Style:
- UELFL
- Bolt Hole Centres:
- 202mm
Technical
Technical
| Shaft diameter | 60mm |
|---|---|
| H | 250mm |
| J | 202mm |
| A<sub>2</sub> | 29mm |
| A<sub>1</sub> | 18mm |
| A | 48mm |
| N | 23mm |
| L | 140mm |
| A<sub>0</sub> | 75.85mm |
| B<sub>1</sub> | 77.8mm |
| S | 30.95mm |
| F min. | 81mm |
| Fixing bolt | M20 |
| Mass | 4.1 kg |
