SKU: UKC316H-SNR
SNR UKC316H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 70mm Bore Insert 60mm Outside Dia - Allow 2-3 Days
SNR UKC316H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 70mm Bore Insert 60mm Outside Dia - Allow 2-3 Days
Regular price
$663.05
ex VAT
Regular price
Sale price
$663.05
ex VAT
In stock
Price Break
3+
$493.96
4+
$474.00
9+
$464.02
19+
$449.06
49+
$439.08
99+
$414.13
499+
$349.27
999+
$0.00
1999+
$0.00
2999+
$0.00
4999+
$0.00
Quantity
Couldn't load pickup availability
Share this product
Description
Description
UKC Series (Medium Duty) Cartridge Bearing Unit with Adaptor Sleeve Mounted: Cast iron cartridge bearing unit supplied with a full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. Cartridge units allow a self aligning bearing inserts to be used where a fixed bearing would normally be used.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, full width insert
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 70mm
- Style:
- UKC
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 70mm |
| A | 60mm |
| A3 | 2.5mm |
| B1 | 78mm |
| d1 | 105mm |
| H | 200mm |
| s1 | 44.5mm |
| G | M10x1 |
| --- | Load rating |
| Dynamic load C | 122.85 kN |
| Static load C0 | 86.5 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Mass | 9.19 kg |
