• Major Branded VLI200544N Four Point Contact Slewing Ring Bearing with Internal Gear 444x648x56mm - Allow 2-3 Days
1 1

SKU: VLI200544N-MB

Major Branded VLI200544N Four Point Contact Slewing Ring Bearing with Internal Gear 444x648x56mm - Allow 2-3 Days

Major Branded VLI200544N Four Point Contact Slewing Ring Bearing with Internal Gear 444x648x56mm - Allow 2-3 Days
$1,423.42 ex VAT
$1,423.42 ex VAT
Sale Sold out

In stock

Price Break
3+ $953.44
5+ $899.88
9+ $889.17
19+ $878.45
49+ $867.74
74+ $857.03
99+ $803.46
199+ $792.75
249+ $782.04
499+ $771.33
999+ $749.90

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Major Brand - High Quality
Inside Diameter:
444mm
Outside Diameter:
648mm
Width:
56mm
Style:
VLI
Technical
--- Main Dimensions & Performance Data
d1 - Bore Diameter 444mm
H - Height 56mm
Da - Outside Diameter 648mm
Outside diameter lower tolerance -0.5mm
Outside diameter upper tolerance 0mm
hf - Height of flange 12mm
ha - Width outer ring 44.5mm
hi - Width inner ring 44.5mm
Weight 39.84 kg
--- Dimensions
Di - Inner diameter outer ring 545.5mm
Inner diameter outer ring upper tolerance 0.5mm
Inner diameter outer ring lower tolerance 0mm
La - Pitch circle diameter fixing holes outer ring 620mm
na - Number of fixing holes in outer ring 10
dB - Fixing bore 18mm
da - Outside diameter inner ring 542.5mm
Outside diameter inner ring upper tolerance 0mm
Outside diameter inner ring lower tolerance -0.5mm
Li - Pitch circle diameter fixing holes inner ring 505mm
dBi - Tread fixing bore M12
Gl - Thread depth fixing hole 20mm
ni - Number of fixing holes in inner ring 16
Fr zul - Max. radial load fixing screws (friction locking) 66100 N
m - Modul of gearing 6mm
z - Number of teeth 76
d0 - Pitch circle diameter gearing 456mm
hA - Ring cross section 20mm
Fz norm - Max. tooth force root fatigue strenght (at a shock factor of 1,2) 23700 N
Fz max - Max. tooth force against tooth fracture (at a shock factor of 1,35) 35000 N
--- Temperature range
Tmin - Operating temperature min. -25 Deg C
Tmax - Operating temperature max. 80 Deg C
--- Calculation factors
Ca - Basic dynamic load rating, axial 152000 N
C0a - Basic static load rating, axial 385000 N
Cr - Basic dynamic load rating, radial 138000 N
C0r - Basic static load rating, radial 144000 N
