• Major Branded VLI200744N Four Point Contact Slewing Ring Bearing with Internal Gear 648x848x56mm - Allow 2-3 Days
1 1

SKU: VLI200744N-MB

Major Branded VLI200744N Four Point Contact Slewing Ring Bearing with Internal Gear 648x848x56mm - Allow 2-3 Days

Major Branded VLI200744N Four Point Contact Slewing Ring Bearing with Internal Gear 648x848x56mm - Allow 2-3 Days
$2,009.89 ex VAT
$2,009.89 ex VAT
Sale Sold out

In stock

Price Break
3+ $1,346.29
5+ $1,270.65
9+ $1,255.52
19+ $1,240.40
49+ $1,225.27
74+ $1,210.14
99+ $1,134.51
199+ $1,119.38
249+ $1,104.26
499+ $1,089.13
999+ $1,058.88

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Major Brand - High Quality
Inside Diameter:
648mm
Outside Diameter:
848mm
Width:
56mm
Style:
VLI
Technical
--- Main Dimensions & Performance Data
d1 - Bore Diameter 648mm
H - Height 56mm
Da - Outside Diameter 848mm
Outside diameter lower tolerance -0.6mm
Outside diameter upper tolerance 0mm
hf - Height of flange 12mm
ha - Width outer ring 44.5mm
hi - Width inner ring 44.5mm
Weight 51.51 kg
--- Dimensions
Di - Inner diameter outer ring 745.5mm
Inner diameter outer ring upper tolerance 0.6mm
Inner diameter outer ring lower tolerance 0mm
La - Pitch circle diameter fixing holes outer ring 820mm
na - Number of fixing holes in outer ring 12
dB - Fixing bore 18mm
da - Outside diameter inner ring 742.5mm
Outside diameter inner ring upper tolerance 0mm
Outside diameter inner ring lower tolerance -0.6mm
Li - Pitch circle diameter fixing holes inner ring 705mm
dBi - Tread fixing bore M12
Gl - Thread depth fixing hole 20mm
ni - Number of fixing holes in inner ring 20
Fr zul - Max. radial load fixing screws (friction locking) 82600 N
m - Modul of gearing 6mm
z - Number of teeth 110
d0 - Pitch circle diameter gearing 660mm
hA - Ring cross section 20mm
Fz norm - Max. tooth force root fatigue strenght (at a shock factor of 1,2) 23700 N
Fz max - Max. tooth force against tooth fracture (at a shock factor of 1,35) 35000 N
--- Temperature range
Tmin - Operating temperature min. -25 Deg C
Tmax - Operating temperature max. 80 Deg C
--- Calculation factors
Ca - Basic dynamic load rating, axial 171000 N
C0a - Basic static load rating, axial 530000 N
Cr - Basic dynamic load rating, radial 155000 N
C0r - Basic static load rating, radial 197000 N
